PUMP
. Cast iron pump body and support
. Brass impeller
. Max. Liquid temperature:+40℃
. Max Suction:+8m
MOTOR
. Motor with copper winding
. Shaft:Stainless steel welded shaft/45# steel be electroplated
. Insulation class:B or F
. Protection class:IP*4
. Max.Ambient temperature:40℃
. Cooling:External ventilation
PUMP INSTALLATION AND APPLICATIONS
It can be used to transfer clean water or other liquids similar to water in physical and chemical properties.It is suitable for industrial use and urban water supply,pressure boosting for high buildings and fire fighting,garden irrigation,long-distance water transfer,heating ventilation and air controlling,circulation and pressure boosting for
cold and hot water,and supporting equipment etc.
