PUMP
. Stainless steel/brass/PPO impeller
. Max. Liquid temperature: +40℃
. Max Suction:+9m
. Cast iron pump body and support
MOTOR
. Motor with copper winding
. Shaft:Stainless steel welded shaft/45# steel be electroplated
. Insulation class:B or F
. Protection class:IP*4
. Max.Ambient temperature:40℃
. Cooling:External ventilation
PUMP INSTALLATION AND APPLICATIONS
It can be used to transfer clean water liquids similar to water in physical and chemical properties.It is suitable for lifting water form the well,sprinkling irrigation in garden, pressure boosting of running water,and supporting equipment etc.
